This quint, built by Spartan on a Spartan Gladiator MFD chassis with a four-door, six-seat cab, will be delivered to Johnson County ESD #1.
The 100-foot aerial is equipped with an obstruction detection and display system with an IQAN advanced control system. It has a 750-pound tip load and the ladder pipe is rated at 1,500-gpm.
The body has rescue-style compartments, rear ladder storage and a Sidestacker hose bed. Features includes LED compartment lighting and slide-out tool trays.
It carries a 2,250-gpm Waterous CSU pump and a 500-gallon UPF Poly Tank III water tank. Additional suppression features include a Trident air prime, Hypro Foam Pro 1600 system and a 25=gallon UPF foam tank.
Emergency warning and lighting equipment includes Whelen F4N mini LED lightbars, a Federal Q2B mechanical siren, Whelen traffic advisor,
It is powered by a 565-hp Cummins X15 motor and Allison EVS4000 transmission and a Kussmaul auto-eject battery conditioner.
